AI Face Recognition + Fingerprint Time Attendance System

AI Face Recognition + Fingerprint Time Attendance System
VV-BS900FR-CAT5
Image of '10.5" Color LCD Display' feature Image of 'Live Face Detection' feature Image of 'Long Range Face Recognition' feature Image of 'Touch Screen' feature Image of 'Waterproof' feature
  • Long range face time and attendance biometric access control system
  • Detection distance more then 8 feet supported
  • User Face capacity of 100,000 face templates
  • 10.5" HD 1300 x 820 Capacitive Touch Screen
  • IP65 waterproof enclosure
  • Alarm notification through voice prompt & software alert
  • Centralized network software for attendance & data management supported
  • 1.2 GHz dual-core ARM Cortex-A7 processor with 512 MB DDR3 RAM, 8 GB eMMC storage and an integrated AI neural processing unit
  • 10.5 inch HD capacitive IPS touch screen at 1300 x 820 pixels resolution for clear and responsive user interaction
  • Dual 2MP Full HD 1080p cameras with 140dB super wide dynamic range and ambient light adaptation up to 10,100 Lux for accurate recognition in any lighting
  • Face recognition distance of 0.5 to 2.6 meters with 99.8% accuracy and recognition speed under 0.2 seconds
  • Stores up to 100,000 face templates, 100,000 fingerprints and 100,000 card IDs with a transaction log of 1,000,000 records
  • Connects via TCP/IP, WiFi and USB 3.0 with Wiegand 26/34 input and output for easy integration with existing access control systems
  • Powered at DC 12V with standby current of 300mA and working current of 500mA, operating from -35°C to 72°C
  • IP65 rated enclosure with humidity tolerance up to 95% for reliable indoor and outdoor deployment
  • Compact body at 299 x 161 x 20 mm weighing just 0.8 kg, certified CE, FCC and RoHS
